Chiller Controller 2 Compressor with Split Board - Megachill 2 Compressor

Chiller Controller 2 Compressor with Split Board - Megachill 2 Compressor

  • 7 segment LED display & LCD with backlight to display all parameters and control status.

  • Audible alarm with LCD message for all faults.

  • HP/LP/OL/OSS trip protection for compressor.

  • Overload trip protection for pump and condenser.

  • Regulates water level via water solenoid valve.

Chiller Controller 2 Compressor with Split Board - Megachill 2 Compressor

Chiller Controller 2 Compressor with Split Board - Megachill 2 Compressor

Display 7 Segment LED Display 3x14.2mm (0.56”) + 16x2 LCD
Probe Inputs Control (Liquid), Antifreeze, Condenser In, Condenser Out
Digital Inputs HP, LP, OSS, AFT, Comp O/L, Cond O/L, Pump O/L, SPP, CCH, CWFS, EWFS, Medium Water Level, Low Water Level, R, Y, B
Relay Outputs Compressor1 : 8(3)A
Compressor2 : 8(3)A
Pump : 5A
Condenser1 : 5A
Condenser2 : 5A
Pump Down SV1 : 5A
Pump Down SV2 : 5A
Water SV : 5A
Alarm : 5A
Buzzer Yes
Power Supply 230Vac Standard
Temperature Range -30.0°C to +50.0°C (Resolution : 0.5°C)
Size 205 x 160mm
Mounting Type Panel Mount, Panel Cutout : 167 x 124mm
Application Chiller Controller
