HVAC&R Controllers

ANNUNCIATOR SZ-85005

ANNUNCIATOR SZ-85005

  • ANNUNCIATOR SZ-85005 is as an Microprocessor based alarm Annunciator to keep an alert and watchful eye on chiller system.

  • It takes input from 6 basic trip signals like HP,LP,COMP OL, SPPR,EWFS of chiller.

  • It has programmable parameters :

    1. 1.To select fault sensing logic as 0 or 230V.

    2. 2.To select auto/manual reset for critical faults like HP,LP.

    3. 3.To add fault sensing delay for LP,EWFS faults to avoid false fault triggering.

ANNUNCIATOR SZ-85005

Display 7 Segment LED Display, 2 x 14.2mm (0.56")
Probe Inputs NTC
Relay Outputs Compressor : 8(3)A
Buzzer Yes
Power Supply 230Vac Standard
Temperature Range -50°C to +99°C
Size 75 x 34.5mm
Mounting Type Panel Mount, Panel Cutout : 71 x 29mm
Application General purpose like chiller machines, lab equipments, display cabinets.

ANNUNCIATOR SZ-85005
